Product Overview
Features
- High permeability of 65%~85%
- Installed inside of the glass does not affect the indoor light
- Thin and light cabinet
- Easy to install and maintain with a specialized double-sided adhesive
- The size can be customized and cut arbitrarily to fit your needs
- Suitable for different scenarios
Specification
Scroll
| Parameters | FT-B4-8-LSFILM | FT-B5-10-LSFILM | FT-B6-5-LSFILM | FT-B8-LSFILM | FT-B10-LSFILM |
|---|---|---|---|---|---|
| Pixel Pitch (mm) | 4*8 | 5*10 | 6.5*6.5 | 8*8 | 10*10 |
| Module Size (mm) | 960*512 | 960*320 | 962*416 | 960*512 | 960*320 |
| Thickness(mm) | 3 | ||||
| Weight (Kg/㎡) | 3.5 | ||||
| Brightness (cd/㎡) | 1500-4500 | ||||
| View Angle | Horizontal: 160°, Vertical: 140° | ||||
| Average Power Consumption (W/㎡) | 240 | ||||
| Peak Power Consumption (W/㎡) | 800 | ||||
| Transparency (%) | ≥60 | ≥65 | ≥55 | ≥60 | ≥65 |
| Frame Rate (Hz) | 1920-3840 | ||||
| Color Temperature | 2000-9500K | ||||
| Power Input | 100V-240V, 50Hz/60Hz | ||||
Case
